Description of power section parameters
Parameters
Power section parameters \ Display values \ Error memory 0-4 \ Error memory t-0–4
There are 5 error memories (t-0 – t-4). The errors are stored in a chronological sequence
with the most recent error event being stored in error memory t-0. If there are more than
5 errors, the error event of longest standing, stored in t-4, is deleted.
Programmable error responses: see chapter "Unit functions/error monitoring".
The following information available at the time of the error is stored and can be used for
detailed diagnostics:
State of binary inputs / binary outputs
Actual speed
Apparent output current
Active current
Unit utilization
Motor utilization
DC link voltage
Power section status
Operating hours
Enable hours
•Work
Heat sink temperature
Motor temperature
Electronics temperature
Error t-0 – 4 error
code index 8366.0,
8367.0, 8368.0,
8369.0, 8370.0
The parameter shows the error group with error number and in plain text.
Error t-0 – 4
sub-error code
index 10072.1,
10072.2, 10072.3,
10072.4, 10072.5
The parameter provides detailed information on the error of an error group.
Error t-0 – 4
internal
index 8883.0,
8884.0, 8885.0,
8886.0, 8887.0
The parameter provides detailed information on the error – can only be evaluated by
SEW-EURODRIVE.
Source of error
t-0 – 4
index 10404.6,
10404.7, 10404.8,
10404.9, 10404.10
The parameter indicates the error source:
•0 = No error
1 = Power section
2 = Command PCB
00
