170
Chit receipt format
*
Item:
Selection:
Entry:
A
Taxable status print
Not print
0
Print
1
B
Q’ty print when q’ty is “1”.
Not print
0
Print
1
C
Dept./PLU/UPC code print
Not print
0
Print
1
D
Unit price print
Not print
0
Print
1
E
Amount print
Not print
0
Print
1
Taxable status print
Taxable status printing is allowed only when “amount print” (parameter E) is set to “Print”.
3656
.@
00000
Ç
Print
Key operation
Example
3656
.
@
Ç
*ABCDE
To program zeros
Procedure
3656
PGM 2
171
173
