175
Secret codes to control access to the PGM1 mode, X1/Z1 mode and X2/Z2
mode
When a secret code has been set for that specific mode operation, before performing any PGM1 mode, X1/Z1
mode or X2/Z2 mode operation, you must enter a secret code according to the following procedure.
Operating
• Once a secret code is entered, it does not need to be entered again unless the mode switch
setting is changed or an operation is performed.
• In case a secret code is forgotten, enter zero to cancel a secret code entry.
Programming
* 2630 for the PGM1 mode
2631 for the X1/Z1 mode
2632 for the X2/Z2 mode
Programming secret code 1234 for X1/Z1 mode
Loading dynamic UPCs to the main UPC file
The UPC master file can be updated by loading the data recorded in the dynamic UPC file to the UPC master
file. Execute the following job.
To Next Page
