Chapter 4 Operating Instructions
CLV65x Bar Code Scanner
34 © SICK AG · Division Auto Ident · Germany · All rights reserved 8011980/0000/2009-04-21
Product description
4.6.6 Increment configuration
The bar code scanner receives information about the conveyor speed from an external in-
cremental encoder, for example. The incremental encoder delivers pulses which are used
to determine the current conveyor speed.
The conveyor speed results from the number of impulses and the resolution of the external
incremental encoder.
4.6.7 Code configuration
The bar code scanner can decode the following code types:
• Codabar
• Code 39
•UPC/EAN
• 2/5 Interleaved
• Code 93
• Code -128 family
•Pharmacode
Note
The increment source and the resolution/speed can be configured using the SOPAS-ET con-
figuration software:
P
ROJECT TREE, CLV65X, PARAMETER, INCREMENT CONFIGURATION, INCREMENT register tab
Note
The code types can be selected and configured using the SOPAS-ET configuration software:
P
ROJECT TREE, CLV65X, PARAMETER, CODE CONFIGURATION, CODE TYPES register tab
The selected code types can be configured individually. For this purpose, separate register
tabs are available in the configuration software SOPAS-ET.
