Chapter 10 Operating Instructions
CLV65x Bar Code Scanner
82 © SICK AG · Division Auto Ident · Germany · All rights reserved 8011980/0000/2009-04-21
Technical data
Tab. 10-1: Technical specifications of the bar code scanner CLV65x (line scanner)
Digital switching outputs Standard version: 2 ("Result 1", "Result 2"), 2 additional outputs via CMC600 in CDB620
Ethernet version: no output, 2 outputs via CMC600 in CDB620
PNP, I
out
= max. 100 mA, short circuit-proof, configurable impulse duration (static, 10 ... 1,000 ms)
Electrical connection Standard version: Cable (0.9 m (3 ft)) with 15-pole D-Sub-HD plug
Ethernet version: Revolving connector unit with two M12 circular connectors
(12-pole plug, 4-pole socket)
Operating voltage
3)
18 ... 30 V DC in accordance with IEC 60364-4-41 (SELV respectively PELV acc. to IEC 60364-4-41
(2005))
Power consumption Line scanner: typically 8.5 W with 18 ... 30 V DC
Housing Die-cast aluminium
Reading window material Glass or plastic, see type plate CLV65x-xxxy
(y = 0: glass, y = 1: plastic)
Electrical safety According to EN 60950-1 (2006-04)
Enclosure rating III, according to EN 61140 (2002-03)
Enclosure rating IP 65, according to EN 60529 (1991-10); A1 (2002-02)
EMV tested Emission: according to EN 61000-6-3 (2007-01); immunity: according to EN 61000-6-2 (2005-08)
Vibration-/ shock-test According to EN 60068-2-6 (1995)/ to EN 60068-2-27 (1993)
Weight Standard version:
320 g (11.3 oz) with connection cable (front reading window), 340 g (12.0 oz)
(side reading window)
Ethernet version:
250 g (8.8 oz) without connection cables (front reading window), 270 g (9.5 oz)
(side reading window)
Ambient operating tempera-
ture/
storage temperature
0 ... +40 °C (32 ...104 °F)/–20 ... +70 °C (-4 ... 158 °F)
Max. rel. humidity 90 %, non condensing
Housing colour Light blue (according to RAL 5012)
1)
Reading gate: code evaluation time window created internally by the reading pulse
2)
Ethernet version: only switching input "Sensor 1"
3)
The bar code scanner CLV65x is certified according to UL60950-1 with the following requirements:
• Power supply by LPS or Class-2 power supply unit
• Use SICK connection cables (category AVL V2 according to UL 758) with a length of up to 3 m (9.84 ft)
The certification applies for devices with appropriate marking on the type plate. The enclosure rating (IP) is not UL certified.
Type Bar code scanner CLV65x
