Operating Instructions Chapter 5
CLV65x Bar Code Scanner
Installation
8011980/0000/2009-04-21 © SICK AG · Division Auto Ident · Germany · All rights reserved 43
5 Installation
5.1 Overview of installation sequences
This chapter describes the installation sequences for the bar code scanner and its external
components.
The typical installation sequences are displayed below:
• Changing the language of the laser warning sign (if necessary)
• Selecting the installation location for the bar code scanner
• Aligning the bar code scanner to the object carrying the bar code
• Installing the bar code scanner
• Installing connection module CDB620 or CDM420
• Connecting the bar code scanner to connection module CDB620 or CDM420
• Adjusting the bar code scanner
• Installing the reading pulse sensor for reading pulse triggering
Important Do not open the bar code scanner's housing. If the device is opened, the SICK AG warranty
shall not apply.
5.2 Installation preparations
Observe the following general requirements for installation:
• Typical space requirement: application specific
• Unobstructed view of the objects for the bar code scanner
• Stable installation bracket with sufficient load capacity and measurements suited to
the bar code scanner (see chapter 10.5 CLV65x bar code scanner diminsional draw-
ings, page 103)
• Shock absorbant and vibration free attachment
The following tools and resources are required for installation:
•Two M5 bolts:
To fix bracket no. 2020410, quick release clamp no. 2025526 or fix bracket
no. 2042800 to the base.
The bolt length depends on the wall thickness of the base.
• Laser warning sign set (if necessary)
•Tool
• Tape measure (up to 1 m (3.28 ft))
•Goniometer
5.2.1 Components to be installed
The following components have to be placed ready for installation:
• CLV65x bar code scanner
