Operating Instructions Chapter 6
CLV65x Bar Code Scanner
Electrical installation
8011980/0000/2009-04-21 © SICK AG · Division Auto Ident · Germany · All rights reserved 55
6.3.1 Electrical connections at the bar code scanner
Important Prerequisites for enclosure rating IP 65:
• The black rubber cover of the memory card (optional) has to be closed and lie flush
against the device.
• The connectors attached to the used electrical connections of the Ethernet version
have to be firmly screwed.
The same applies to the EMC requirement (ESD) according to CE.
Depending on the device version, the following electrical connections are available at the
bar code scanner:
Tab. 6-1: Electrical connections to the bar code scanner with a fixed cable and connector
(standard version)
Tab. 6-2: Electrical connections to the bar code scanner with connector unit (Ethernet version)
Important Additional digital inputs and outputs are available at connection module CDB620/CDM420
(available from week 07/2008) in combination with the parameter memory module
CMC600.
Device version Connection (design) Interfaces For connection to
CLV65x-0000
CLV65x-1000
CLV65x-2000
CLV65x-3000
CLV65x-6000
Cable with connector
(D-Sub-HD, 15-pole, plug)
• RS-232
• RS-422/485
•CAN
• Two digital inputs
•Two digital outputs
•Power supply
e. g. connection
module CDB620 or
CDM420
Device version Connection (design) Interfaces For connection to
CLV65x-0120
CLV65x-1120
CLV65x-2120
CLV65x-3120
CLV65x-6120
Connector 1 at the connec-
tor unit
(M-12, 4-pole, socket)
• Ethernet Network provided by
the client
Connector 2 at the connec-
tor unit
M-12, 12-pole, plug
• RS-232
• RS-422/485
•CAN
•One digital input
•Power supply
e. g. connection
module CDB620 or
CDM420
