Operating Instructions Chapter 10
CLV65x Bar Code Scanner
Technical data
8011980/0000/2009-04-21 © SICK AG · Division Auto Ident · Germany · All rights reserved 83
10.2 Data sheet for the CLV65x bar code scanner (line scanner
with oscillating mirror)
The technical specifications correspond to those of the CLV65x bar code scanner (line scanner), except for the following
variations:
Tab. 10-2: Technical specifications for the CLV65x bar code scanner (line scanner with oscillating mirror)
10.3 Addition to UL certification
Tab. 10-3: Technical specifications for UL certification: bar code scanner with connection cable
from 0.9 m (1 ft) up to 6 m (19.7 ft)
Type Bar code scanner CLV65x
Reading window Side reading window, light exit under 105° (default setting)
Useable aperture angle Max. 50°
Oscillating mirror functions Uncontrolled operation:
• Fixed (position can be adjusted) or
• Continuous, free oscillation
Controlled operation (start/stop condition can be adjusted):
• Triggered oscillation (start position and number of oscillations can be adjusted)
• One-shot: One-time oscillation in forward and return motion (start position can be adjusted)
In every oscillation mode, the amplitude can be adjusted separately for each of the two deflection
directions. The deflection speed ratio of one deflection direction to the other can be adjusted within
the selected periodic time for a complete oscillation sequence.
Oscillation frequency / Periodic
time
0.5 ... 6.25 Hz/2,000 ... 160 ms
Max. angle of deflection (ampli-
tude)
+20° ... –20°
Power consumption Typically 9.5 W with 18 ... 30 V DC
Weight Standard version: 420 g (14.8 oz)
Ethernet version: 350 g (12.3 oz)
Type Supply voltage Power consumption Power input Ambient operating
temperature
CLV650-0xxx
18 ... 30 V DC
8.5 W Max. 800 mA 0 ... +40 °C
(32 ... 104 °F)
CLV650-6xxx
18 ... 30 V DC
9.5 W Max. 800 mA 0 ... +40 °C
(32 ... 104 °F)
CLV651-0xxx
18 ... 30 V DC
8.5 W Max. 800 mA 0 ... +40 °C
(32 ... 104 °F)
CLV651-6xxx
18 ... 30 V DC
9.5 W Max. 800 mA 0 ... +40 °C
(32 ... 104 °F)
