Chapter 5 Operating Instructions

CLV65x Bar Code Scanner

Installation

5.5.3 Installing the incremental encoder

An incremental encoder is required for separating bar codes with the same code type and

identical content.

The increment impulses have to come from the conveyor system area where the bar code

scanner is reading.

1. Install suitable increment encoders near to the bar code scanner, best against the di-

rection of the conveyor system in front of the bar code scanner.

2. Ensure that the incremental encoder has direct and fixed contact with the drive system

and that the friction wheel rotates without slipping.

5.6 Removing the bar code scanner

Removal of the components is described in chapter 8.5.1 Removing the bar code scanner,

page 78.
