Operating Instructions Chapter 7
CLV65x Bar Code Scanner
Startup and configuration
8011980/0000/2009-04-21 © SICK AG · Division Auto Ident · Germany · All rights reserved 71
7.4.2 Configuring the bar code scanner
All configurable parameters for the bar code scanner are grouped into a device description
(jar-file) for the SOPAS-ET configuration software. The device description's project tree acts
as a guideline for the configuration.
The function of each respective parameter is explained in a context-sensitive manner in an
online help (F1 key). The valid value range and the default setting list the display window
P
ARAMETER INFO (right mouse button, when the cursor is positioned over the parameter).
1. In the menu bar under T
OOLS select the command LOGIN DEVICE.
2. Select the entry A
UTHORIZED CLIENT in the dialog window under USERLEVEL in the list box.
If the parameter set is password-protected, enter the password "client" in P
ASSWORD.
Activate/deactivate password protection on the P
ARAMETER register tab.
3. Click on OK to confirm the dialog window.
The previously greyed out parameters on the register tabs are now accessible.
7.4.3 Permanently load changed parameter sets into the device
Changed parameter values are immediately transferred to the bar code scanner's main me-
mory (RAM) depending on the option (“Immediate download“). To ensure that the changes
remain even after the bar code scanner is restarted, the configuration has to be permanent-
ly saved in the bar code scanner's PROM.
In order to load the current settings permanently in the bar code scanner, select the
command P
ARAMETER/SAVE PERMANENT in the menu bar under CLV65X or click on in
the tool bar.
Note
In order to configure a device via the SOPAS-ET configuration software, the respective ope-
rating level has to be selected in advance. After the start, the SOPAS-ET configuration soft-
ware functions at the operating level "M
AINTENANCE".
