Chapter 10 Operating Instructions

CLV65x Bar Code Scanner

Technical data

Fig. 10-4: Depth of field ranges of the CLV650 line scanner with front reading window: min. und max. reading distance depending on

the focus position and the aperture angle with a resolution of 0.35 mm (13.8 mil)
