3 SYSTEMS DESCRIPTION
3.1 ALIS Laser - Laser Based Bar Code Reading System
Fig. 1: Components of the 6 side ALIS reading gate based on laser scanners
Legend
1
Eight CLV691 fixed mount bar code scanner
2
Cabinet with controller and power supply unit
3
Field bus module for PROFINET (optionally)
4
Two CLV691 fixed mount bar code scanner with cleaning unit
optionally 3 - 4 CLV651 fixed mount bar code scanners with
cleaning unit and connection unit
5
Incremental signal
6
Trigger signal
