8 OPERATION
8.2.3 Lector654 Code Reader
Fig. 28: Operational readiness of the Lector654
● The Ready I Tst LED lights up.
8.2.4 RFU630
Fig. 29: Optical status indicators on the display
● The Ready LED lights up green
8.2.5 MSC800 System Controller
Fig. 30: Operational readiness of the MSC800 system controller
● The DEVIDE READY LED lights up
8.2.6 System Readiness
Fig. 31: System readiness
● In addition to the DEVICE READY LED, the SYSTEM READY LED also lights up on the
MSC800 system controller
