9 MAINTENANCE AND REPAIR
9.4.5 MSC800 Battery Replacing
A battery powers the real-time clock of the MSC800 system controller. The battery must be
replaced when drained.
Fig. 55: Location of the battery
▸ Remove the black plastic cover on the MSC800.
▸ Remove the battery from the bracket and replace it with a new CR2032 battery.
▸ Put the black plastic cover back in place.
▸ Dispose of the old battery as hazardous waste as per the ROHS directives (Europe).
▸ Set the system time again using the SOPAS software
(Project tree  MSC800  System  REAL-TIME CLOCK area).
