8027605/V1-0/2022-03| SICK S Y S T E M D E S C R I P T I O N | ALIS
Subject to change without notice
OPERATION 8
8.2.7 Automated Operating Mode
The track and trace system runs fully automated after startup. No manual intervention by
the operator is required
Minimum distance and rotational position
Fig. 32: Minimum distance and rotational position
Legend
1
ALIS Laser or Camera:
– minimum distance between bags >150mm
ALIS RFID:
– minimum distance between bags >400mm
2
ALIS Laser or Camera:
– minimum distance between two bar codes >50mm
ALIS RFID:
– minimum distance between RFID tags >400mm
3
Rotational position of bag and IATA code as desired
Note
If the bags rotate, vibrate, roll, or slip on the conveyor system and if the conveying sur-
faces are uneven, the read result may be affected.
