Chapter 12 Operating instructions
S100
58 © SICK AG • Subject to change without notice 8012238/YY30/2015-02-20
Technical specifications
Minimum Typical Maximum
Application diagnostics outputs 1 and 2
HIGH switching voltage at 200 mA U
V
– 3.3 V U
V
Source switching current 100 mA 200 mA
Current limiting (in accordance with 5 ms at
25°C)
600 mA 920 mA
Power up delay 1.4 ms 2 ms
Switch off delay 0.7 ms 2 ms
Configuration and diagnostics interface
Communication protocol RS232 (proprietary)
Transmission speed 38400 Baud
Cable length at 38400 Baud and 0.25 mm²
cables
15 m
Galvanic de-coupling No
Output TxD HIGH 5 V 15 V
Output TxD LOW –15 V –5 V
Voltage range RxD –15 V 15 V
Switching threshold RxD LOW –15 V 0.4 V
Switching threshold RxD HIGH 2.4 V 15 V
Short-circuit current at TxD –60 mA 60 mA
Max. voltage level at RxD –15 V 15 V
Max. voltage level at TxD –11 V 11 V
