SICK scanGrid2 I/O User Manual

Table 8: Pin assignment of the connecting cable with 8-pin M12 plug connector
PIN Designation Function
1 +24 V DC Supply voltage (+24 V DC)
2 OSSD1 OSSD1 (switching output 1)
3 0 V DC Supply voltage (0 V DC)
4 OSSD2 OSSD2 (switching output 2)
5 Uni-O Universal output, configurable: monitoring result, conta‐
mina
tion, error
6 IN 1 Control input 1: Monitoring case switching
7 IN 2 Control input 2: Monitoring case switching
8 IN 3 Control input 3: Monitoring case switching
6 ELECTRICAL INSTALLATION
40
O P E R A T I N G I N S T R U C T I O N S | scanGrid2 I/O 8025936/2021-01-08 | SICK
Subject to change without notice
