SICK scanGrid2 I/O User Manual

Access protection
In an ac
cess protection system, if a person passes through the protective field with
their whole body, they are detected and a stop signal is triggered.
A person standing behind the protective device will not be detected by the ESPE.
NOTICE
T
o prevent the access protection from being manipulated, install a mechanical manip‐
ulation protection. This prevents the safe multibeam scanner from being manually
misadjusted.
Figure 7: Access protection: detection of a person before they access a hazardous area
PRODUCT DESCRIPTION 3
8025936/2021-01-08 | SICK O P E R A T I N G I N S T R U C T I O N S | scanGrid2 I/O
15
Subject to change without notice
