Ambient operating tempera‐
t
ure
0 °C … 50 °C
Storage temperature –30 °C … 70 °C
Air humidity 15% ... 95%, non-condensing
3)
Height above sea level during
oper
ation
≤ 3,000 m
EMC According to IEC 61496-1, IEC 61000-6-2, IEC 61000-6-3
Vibration resistance
4)
Standards
•
IE
C 60068-2-6
•
IEC 60068-2-64
•
IEC 60721-3-5
•
IEC TR 60721-4-5
•
IEC 61496-3
Class 5M1 (IEC 60721-3-5)
Sinusoidal vibrations
•
0.35 mm, 50 m/s
2
, 10 Hz … 55 Hz
•
1.5 mm, 1 Hz … 9 Hz
•
5 m/s
2
, 9 Hz … 200 Hz
Noise vibrations
•
0.5 m
2
/s
3
, 10 Hz … 200 Hz
•
0.1 m
2
/s
3
, 200 Hz … 500 Hz
Shock resistance
4)
Standards
•
IE
C 60068-2-27
•
IEC 60721-3-5
•
IEC TR 60721-4-5
•
IEC 61496-3
Class 5M1 (IEC 60721-3-5)
Single shock 150 m/s
2
, 11 ms
Continuous shock 100 m/s
2
, 16 ms
1)
The specified enclosure rating only applies when the USB connection is sealed with the protective cover.
2)
Against indirect ambient light (reflected from the background) according to IEC 61496-3: ≤ 1,500 lx
3)
IEC 61496-1, no. 4.3.1 and no. 5.4.2, IEC 61496-3, no. 4.3.1 and no. 5.4.2. Condensation has an
inf
luence on normal operation.
4)
For direct mounting.
Table 23: Miscellaneous data
Type of light Pulsed laser diode
Wavelength 850 nm
Detectable remission 4% … several 1,000%
Maximum uniform contamina‐
t
ion of the front screen with‐
out reducing the detection
capability
1)
30%
Area where detection capabil‐
ity is restricted
≤ 50 mm
2)
Pulse duration Typ. 1.5 ns
Laser class 1
3)
13 TECHNICAL DATA
76
O P E R A T I N G I N S T R U C T I O N S | scanGrid2 I/O 8025936/2021-01-08 | SICK
Subject to change without notice
