The FEM_AI has the following output parameters:
Table 5-8 Output parameters of the FEM_AI
Parameter Comment Data type Default
BLOCKCON Block connector STRUCT 0
QRACKF_1A 1 = Rack Failure Channel A Unit 1 BOOL 0
QMODF_1A 1 = Modul Failure Channel A Unit 1 BOOL 0
QPERF_1A 1 = I/O Access Failure Channel A Unit 1 BOOL 0
QPARF_1A 1 = Parameter Assignment Failure Channel A Unit 1 BOOL 0
QRACKF_1B 1 = Rack Failure Channel B Unit 1 BOOL 0
QMODF_1B 1 = Module Failure Channel B Unit 1 BOOL 0
QPERF_1B 1 = I/O Access Failure Channel B Unit 1 BOOL 0
QPARF_1B 1 = Parameter Assignment Failure Channel A Unit 1 BOOL 0
QRACKF_2A 1 = Rack Failure Channel A Unit 2 BOOL 0
QMODF_2A 1 = Modul Failure Channel A Unit 2 BOOL 0
QPERF_2A 1 = I/O Access Failure Channel A Unit 2 BOOL 0
QPARF_2A 1 = Parameter Assignment Failure Channel A Unit 2 BOOL 0
QRACKF_2B 1 = Rack Failure Channel B Unit 2 BOOL 0
QMODF_2B 1 = Modul Failure Channel B Unit 2 BOOL 0
QPERF_2B 1 = Access Failure Channel B Unit 2 BOOL 0
QPARF_2B 1 = Parameter Assignment Failure Channel A Unit 2 BOOL 0
QCH1_F 1 = Channel Failure AI1 BOOL 0
QCH2_F 1 = Channel Failure AI2 BOOL 0
QCH3_F 1 = Channel Failure AI3 BOOL 0
QCH4_F 1 = Channel Failure AI4 BOOL 0
QCH5_F 1 = Channel Failure AI5 BOOL 0
QCH6_F 1 = Channel Failure AI6 BOOL 0
QCH7_F 1 = Channel Failure AI7 BOOL 0
QCH8_F 1 = Channel Failure AI8 BOOL 0
QCH9_F 1 = Channel Failure AI9 BOOL 0
QCH10_F 1 = Channel Failure AI10 BOOL 0
QCH11_F 1 = Channel Failure AI11 BOOL 0
QCH12_F 1 = Channel Failure AI12 BOOL 0
AI1_VAL Analog Input 1 Value REAL 0
AI2_VAL Analog Input 2 Value REAL 0
AI3_VAL Analog Input 3 Value REAL 0
AI4_VAL Analog Input 4 Value REAL 0
AI5_VAL Analog Input 5 Value REAL 0
AI6_VAL Analog Input 6 Value REAL 0
AI7_VAL Analog Input 7 Value REAL 0
AI8_VAL Analog Input 8 Value REAL 0
AI9_VAL Analog Input 9 Value REAL 0
