Parameter Comment Data type Visible Default
AO8_VAL Analog Output 8 Value REAL Yes 0.0
AO8_HRNG Analog Output 8 High Range REAL Yes 100.0
AO8_LRNG Analog Output 8 Low Range REAL Yes –100.0
AO8_SIM Simulation Value Analog Output 8 REAL No 0.0
SIMUL8 1 = Simulation on BOOL No 0
The FEM_AO has the following output parameters:
Table 5-10 Output parameters of the FEM_AO
Parameter Comment Data type Default
QPARF 1 = Parameter Assignment Failure BOOL 0
QCH1_F 1 = Channel Failure AO1 BOOL 0
QCH2_F 1 = Channel Failure AO2 BOOL 0
QCH3_F 1 = Channel Failure AO3 BOOL 0
QCH4_F 1 = Channel Failure AO4 BOOL 0
QCH5_F 1 = Channel Failure AO5 BOOL 0
QCH6_F 1 = Channel Failure AO6 BOOL 0
QCH7_F 1 = Channel Failure AO7 BOOL 0
QCH8_F 1 = Channel Failure AO8 BOOL 0
5.6.3 FEM_DI – Binary Input
The following OBs must call the function block FEM_DI:
Watchdog interrupt OB for cyclic operation (for example OB 32).
Area of Application
The block outputs the binary input data of the AddFEM to its output bar.
Functional Description
The block reads the binary inputs from the AddFEM. The inputs DI5 to DI12 are
pure binary inputs. DI1 to DI3 are the pulse inputs of the counters. Input 4 is not
assigned and is therefore also not specified in the block bar. The inputs DIO1 to
DIO16 are combined inputs and outputs. They can be used both as inputs and as
outputs. Each digital input can be switched to simulation by means of a simulation
switch. If the switch SIMUDIx = 1, the simulation value DIx_SIM is output.
