Commissioning / Operation / Maintenance AddFEM
5-54
AddFEM
C79000–G8076–C900–03
Parameters
The FEM_AO has the following input parameters:
Table 5-9 Input parameters of the FEM_AO
Parameter Comment Data type Visible Default
BLOCKCON Block connector STRUCT Yes 0
AO1_VAL Analog Output 1 Value REAL Yes 0.0
AO1_HRNG Analog Output 1 High Range REAL Yes 100.0
AO1_LRNG Analog Output 1 Low Range REAL Yes –100.0
AO1_SIM Simulation Value Analog Output 1 REAL No 0.0
SIMUL1 1 = Simulation on BOOL No 0
AO2_VAL Analog Output 2 Value REAL Yes 0.0
AO2_HRNG Analog Output 2 High Range REAL Yes 100.0
AO2_LRNG Analog Output 2 Low Range REAL Yes –100.0
AO2_SIM Simulation Value Analog Output 2 REAL No 0.0
SIMUL2 1 = Simulation on BOOL No 0
AO3_VAL Analog Output 3 Value REAL Yes 0.0
AO3_HRNG Analog Output 3 High Range REAL Yes 100.0
AO3_LRNG Analog Output 3 Low Range REAL Yes –100.0
AO3_SIM Simulation Value Analog Output 3 REAL No 0.0
SIMUL3 1 = Simulation on BOOL No 0.0
AO4_VAL Analog Output 4 Value REAL Yes 0.0
AO4_HRNG Analog Output 4 High Range REAL Yes 100.0
AO4_LRNG Analog Output 4 Low Range REAL Yes –100.0
AO4_SIM Simulation Value Analog Output 4 REAL No 0.0
SIMUL4 1 = Simulation on BOOL No 0
AO5_VAL Analog Output 5 Value REAL Yes 0.0
AO5_HRNG Analog Output 5 High Range REAL Yes 100.0
AO5_LRNG Analog Output 5 Low Range REAL Yes –100.0
AO5_SIM Simulation Value Analog Output 5 REAL No 0.0
SIMUL5 1 = Simulation on BOOL No 0
AO6_VAL Analog Output 6 Value REAL Yes 0.0
AO6_HRNG Analog Output 6 High Range REAL Yes 100.0
AO6_LRNG Analog Output 6 Low Range REAL Yes –100.0
AO6_SIM Simulation Value Analog Output 6 REAL No 0.0
SIMUL6 1 = Simulation on BOOL No 0
AO7_VAL Analog Output 7 Value REAL Yes 0.0
AO7_HRNG Analog Output 7 High Range REAL Yes 100.0
AO7_LRNG Analog Output 7 Low Range REAL Yes –100.0
AO8_SIM Simulation value output 7 REAL No 0.0
SIMUL7 1 = Simulation on BOOL No 0
