Technical Data AddFEM
4-2
AddFEM
C79000–G8076–C900–03
4.1 AddFEM
General Data
Dimensions (Height x Width x Depth) 295 mm x 75 mm x 209 mm
Mass 2.8 kg
Input voltage,
Nominal value
Valid range
24 V DC
static: 19.2 to 30 V DC
dynamic: 18.5 to 30.2 V
Nominal input current
Module supply
Load supply
0.8 A
8 A
Starting current
Peak value
Half–value width
3 A limited
100 ms
Overriding of power failures At least 10 ms (at input voltage 19.2 to 30 V
DC)
Power loss arising in the AddFEM
– Module supply
– Power input at the digital inputs
– Power input at the analog inputs
– Switching and transmission losses of the
digital outputs supplied via the load supply
max. 33 W (sum)
max. 20 W
max. 4 W
max. 1 W
max. 8 W
Module supply fuse F 2.5 A (internal as protection against da-
mage, cannot be replaced)
Load supply fuse 2 x F 7 A (internal as protection against da-
mage, cannot be replaced)
Control–to–load isolation
The module consists of several function groups which are isolated from each other. In operation
the max. permitted potential difference between these function groups amounts to 50 V. The
signals/connections are assigned to the individual function groups as follows:
a) Analog inputs and outputs (plug connections X4/1 to X4/20 and X5/1 to X5/20) including
internal micro controller area
b) Counting pulse inputs (plug connections X6/1 to X6/4)
c) Digital inputs 5 to 8 (plug connections X6/6 to X6/10)
d) Digital inputs 9 to 12 (plug connections X6/11 to X6/15)
e) Digital inputs 13 to 16 (plug connections X6/16 to X6/20)
f) Digital outputs 1 to 8 (plug connections X7/1 to X7/10)
g) Digital outputs 9 to 16 (plug connections X7/11 to X7/20)
h) PROFIBUS DP connection to connector X3A
i) PROFIBUS DP connection to connector X3B
j) Module supply 24 V DC
k) Housing
