AddFEM
Design
2-7
AddFEM
C79000–G8076–C900–03
2.3 Connection Elements
X1 Service
interface
X2 Redundancy
interface
X3A PROFIBUS DP
connection
X3B PROFIBUS DP
connection
Module supply
24 V DC
Grounding screw
X4 Process signals
“Analog Out/In”
X5 Process signals
“Analog In”
X6 Process signals
“Digital In”
X7 Process signals
“Digital Out”
Figure 2-3 Connection elements
