Front Connector Configuration
Overview
The following tables list the pin configuration of the connectors X4 to X7.
Connector X4
Pin No. Name Function Pin No.
Name Function
1 NC Not assigned 11 NC Not assigned
2 S1+ Analog output Channel 1 12 M1+ Analog input Channel 1+
3 S2+ Analog output Channel 2 13 M1– Analog input Channel 1–
4 S3+ Analog output Channel 3 14 M2+ Analog input Channel 2+
5 S4+ Analog output Channel 4 15 M2– Analog input Channel 2–
6 S5+ Analog output Channel 5 16 M3+ Analog input Channel 3+
7 S6+ Analog output Channel 6 17 M3– Analog input Channel 3–
8 S7+ Analog output Channel 7 18 M4+ Analog input Channel 4+
9 S8+ Analog output Channel 8 19 M4– Analog input Channel 4–
10 M Signal common AO / AI 20 M Signal common AI
Connector X5
Pin No. Name Function Pin No.
Name Function
1 NC Not assigned 11 NC Not assigned
2 M5+ Analog input Channel 5+ 12 M9+ Analog input Channel 9+
3 M5– Analog input Channel 5– 13 M9– Analog input Channel 9–
4 M6+ Analog input Channel 6+ 14 M10+ Analog input Channel 10+
5 M6– Analog input Channel 6– 15 M10– Analog input Channel 10–
6 M7+ Analog input Channel 7+ 16 M11+ Analog input Channel 11+
7 M7– Analog input Channel 7– 17 M11– Analog input Channel 11–
8 M8+ Analog input Channel 8+ 18 M12+ Analog input Channel 12+
9 M8– Analog input Channel 8– 19 M12– Analog input Channel 12–
10 M Signal common AI 20 M Signal common AI
