The FEM_DI has the following output parameters:
Table 5-12 Output parameters of the FEM_DI
Parameter Comment Data type Default
BLOCKCNO Block Connector Output STRUCT 0
QPARF 1 = Parameter Assignment Failure BOOL 0
QALLCH 1 = All Channels Failure BOOL 0
DI_1 Digital Input 1 (Counter Input) BOOL 0
DI_2 Digital Input 2 (Counter Input) BOOL 0
DI_3 Digital Input 3 (Counter Input) BOOL 0
DI_5 Digital Input 5 BOOL 0
DI_6 Digital Input 6 BOOL 0
DI_7 Digital Input 7 BOOL 0
DI_8 Digital Input 8 BOOL 0
DI_9 Digital Input 9 BOOL 0
DI_10 Digital Input 10 BOOL 0
DI_11 Digital Input 11 BOOL 0
DI_12 Digital Input 12 BOOL 0
DI_13 Digital Input 13 BOOL 0
DI_14 Digital Input 14 BOOL 0
DI_15 Digital Input 15 BOOL 0
DI_16 Digital Input 16 BOOL 0
DIO_1 Digital Input/Output 1 BOOL 0
DIO_2 Digital Input/Output 2 BOOL 0
DIO_3 Digital Input/Output 3 BOOL 0
DIO_4 Digital Input/Output 4 BOOL 0
DIO_5 Digital Input/Output 5 BOOL 0
DIO_6 Digital Input/Output 6 BOOL 0
DIO_7 Digital Input/Output 7 BOOL 0
DIO_8 Digital Input/Output 8 BOOL 0
DIO_9 Digital Input/Output 9 BOOL 0
DIO_10 Digital Input/Output 10 BOOL 0
DIO_11 Digital Input/Output 11 BOOL 0
DIO_12 Digital Input/Output 12 BOOL 0
DIO_13 Digital Input/Output 13 BOOL 0
DIO_14 Digital Input/Output 14 BOOL 0
DIO_15 Digital Input/Output 15 BOOL 0
DIO_16 Digital Input/Output 16 BOOL 0
