Commissioning / Operation / Maintenance AddFEM
5-62
AddFEM
C79000–G8076–C900–03
The FEM_DO has the following input parameters (continued):
Parameter Comment Data type Visible Default
SIMUDO12 1 = Simulation on BOOL No 0
DO13_VAL Output Value DO13 BOOL Yes 0
DO13_SM Simulation Value DO13 BOOL No 0
SIMUDO13 1 = Simulation on BOOL No 0
DO4_VAL Output Value DO14 BOOL Yes 0
DO14_SM Simulation Value DO14 BOOL No 0
SIMUDO14 1 = Simulation on BOOL No 0
DO15_VAL Output Value DO15 BOOL Yes 0
DO15_SM Simulation Value DO15 BOOL No 0
SIMUDO15 1 = Simulation on BOOL No 0
DO16_VAL Output Value DO16 BOOL Yes 0
DO16_SM Simulation Value DO16 BOOL No 0
SIMUDOO16 1 = Simulation on BOOL No 0
The FEM_DO has the following output parameters:
Table 5-14 Output parameters of the FEM_DO
Parameter Comment Data type Default
BLOCKCNO Block Connector Output STRUCT 0
QPARF 1 = Parameter Assignment Failure BOOL 0
QCH1_F 1 = Channel Failure DO1 BOOL 0
QCH2_F 1 = Channel Failure DO2 BOOL 0
QCH3_F 1 = Channel Failure DO3 BOOL 0
QCH4_F 1 = Channel Failure DO4 BOOL 0
QCH5_F 1 = Channel Failure DO5 BOOL 0
QCH6_F 1 = Channel Failure DO6 BOOL 0
QCH7_F 1 = Channel Failure DO7 BOOL 0
QCH8_F 1 = Channel Failure DO8 BOOL 0
QCH9_F 1 = Channel Failure DO9 BOOL 0
QCH10_F 1 = Channel Failure DO10 BOOL 0
QCH11_F 1 = Channel Failure DO11 BOOL 0
QCH12_F 1 = Channel Failure DO12 BOOL 0
QCH13_F 1 = Channel Failure DO13 BOOL 0
QCH14_F 1 = Channel Failure DO14 BOOL 0
QCH15_F 1 = Channel Failure DO15 BOOL 0
QCH16_F 1 = Channel Failure DO16 BOOL 0
