Siemens Add 7 AddFEM User Manual

AddFEM
Commissioning / Operation / Maintenance
5-61
AddFEM
C79000–G8076–C900–03
Parameters
The FEM_DO has the following input parameters:
Table 5-13 Input parameters of the FEM_DO
Parameter Comment Data type Visible Default
BLOCKCNI Block Connector Input STRUCT Yes 0
DO1_VAL Output Value DO1 BOOL Yes 0
DO1_SIM Simulation Value DO1 BOOL No 0
SIMUDO1 1 = Simulation on BOOL No 0
DO2_VAL Output Value DO2 BOOL Yes 0
DO2_SIM Simulation Value DO2 BOOL No 0
SIMUDO2 1 = Simulation on BOOL No 0
DO3_VAL Output Value DO3 BOOL Yes 0
DO3_SIM Simulation Value DO3 BOOL No 0
SIMUDO3 1 = Simulation on BOOL No 0
DO4_VAL Output Value DO4 BOOL Yes 0
DO4_SIM Simulation Value DO4 BOOL No 0
SIMUDO4 1 = Simulation on BOOL No 0
DO5_VAL Output Value DO5 BOOL Yes 0
DO5_SIM Simulation Value DO5 BOOL No 0
SIMUDO5 1 = Simulation on BOOL No 0
DO6_VAL Output Value DO6 BOOL Yes 0
DO6_SIM Simulation Value DO6 BOOL No 0
SIMUDO6 1 = Simulation on BOOL No 0
DO7_VAL Output Value DO7 BOOL Yes 0
DO7_SIM Simulation Value DO7 BOOL No 0
SIMUDO7 1 = Simulation on BOOL No 0
DO8_VAL Output Value DO8 BOOL Yes 0
DO8_SIM Simulation Value DO8 BOOL No 0
SIMUDO8 1 = Simulation on BOOL No 0
DO9_VAL Output Value DO9 BOOL Yes 0
DO9_SIM Simulation Value DO9 BOOL No 0
SIMUDO9 1 = Simulation on BOOL No 0
DO10_VAL Output Value DO10 BOOL Yes 0
DO10_SIM Simulation Value DO10 BOOL No 0
SIMUDO10 1 = Simulation on BOOL No 0
DO11_VAL Output Value DO11 BOOL Yes 0
DO11_SIM Simulation Value DO11 BOOL No 0
SIMUDO11 1 = Simulation on BOOL No 0
DO12_VAL Output Value DO12 BOOL Yes 0
DO12_SIM Simulation Value DO12 BOOL No 0
