AddFEM in
Operating Mode 2
Fig. 3-3 Configuration with operating mode 2
Host: Single–channel
AddFEM: Redundant with optical–fiber cable redun-
dancy coupling
AddFEM in
Operating Mode 3
Fig. 3-4 Configuration with operating mode 3
Host: Redundant
AddFEM: Redundant with optical–fiber cable redun-
dancy coupling
