3-20 System- and communication configuring D7-SYS - SIMADYN D
Edition 12.2003
− 3rd octet to 6th octet:
Specify the time between 00:00 and 24:00.
Resolution = 1ms
0 ms≤x≤86400000 ms
The first 4 bits are not assigned in the sixth octet
0000 xxxx xxxx xxxx xxxx xxxx xxxx xxxx dddd dddd dddd dddd
6.octet 1.octet
Significance 2
27
2.octet3.octet
Significance 2
00
Significance 2
15
Si
g
nificance 2
00
Fig. 3-7 Time and date
3.1.4.4 Number of coupling modules in a subrack
The number of CS coupling modules (CSH11, CS12/13/14, CS22 and
CS7) are restricted by two system limits:
• subrack size
The largest subrack in the SIMADYN D system has 24 slots. As a
subrack must have at least one CPU, theoretically, 23 slots remain.
• available address space
In practice, these limits are seldomly reached. For CS modules, the L-
and C bus each have 1 Mbyte address space.
The individual CS modules always occupy a constant address space on
the backplane bus.
• Example
CS7 always occupies 64 Kbyte on the L bus, independent of how
many modules are configured.
Module type Backplane bus Occupied address space
CS12/13/14, CS22 C bus 128 Kbyte
CSH11 C bus 64 Kbyte
CS7 L bus 64 Kbyte
Table 3-16 Occupied address space
3.1.4.5 Reorganizing a data interface
A data interface can be re-formatted without having to interrupt the RUN
condition or diminish performance.
Overview
Assigned address
space
General
