Communications configuring
System- and communication configuring D7-SYS - SIMADYN D 3-63
Edition 12.2003
Error class Error code Significance
0
(alarm)
0 O.K.
1
COM database present, but not activated as the baud rate and the
PROFIBUS address with connections BDR and MAA do not match.
• Remedy: Harmonize the baud rate and PROFIBUS address in the CFC
and COM configuring.
2 No COM database available.
• Remedy: Load the database.
3 The COM database is presently being downloaded with subsequent start-up.
4
The channels to DP nodes, configured with CFC, which are configured in the
COM database, are missing. This status can also temporarily occur after a
SIMADYN D run-up. The DP nodes are not addressed.
• Remedy: Harmonize the CFC- and COM configuring.
5 (not used)
6
There is at least one channel configured with CFC which does not match the
COM database. The associated SIMADYN D FB has issued a
communications error (flashing ”C”).
• Remedy: Harmonize the CFC- and COM configuring.
7
There is at least one channel configured with CFC, which essentially does not
match the COM database. The associated SIMADYN D-FB has issued a
communications error (flashing ”C”).
• Correct the CFC configuring.
8 Resource bottleneck. Not all of the CFC channels are processed.
• Remedy: Reduce the CFC configuring (communication channels).
9
There are two channels, which wish to transmit data to the same slave or
receive data from it. The SIMADYN D-FB which is associated with the
channel which addressed the slave later, has issued a communications error
(flashing ”C”).
• Remedy: Correct the CFC configuring.
10 Bus operation temporarily faulted.
• Remedy: Check the cable and bus nodes.
>1
(internal
error)
(any)
• Remedy: Note the error class and error code and inform Siemens AG.
Table 3-29 Significance of the error class and error code
3.5.3.3 Application example, PROFIBUS DP coupling
The application example describes a typical configuration consisting of:
• SIMOVERT 6SE70
• ET200U
• ET200B
• SIMATIC S5
General
