Communications configuring
3-182 System- and communication configuring D7-SYS - SIMADYN D
Edition 12.2003
The following errors can occur and are displayed at the ERROR output:
Error code Explanation Remedy
0xB210 OK -
0xB211 Logical module address invalid
Specify a valid module address at input
LADDR.
0xB212 Data set number not valid
Enter the tabular values in an increasing
sequence in the DB.
0xB213 Invalid table data format
Tabular values must have data type REAL for
the TAB and data type DINT for the TAB_D.
0xB214
The data format of the new data set
does not match that of the previously
transferred data set
Ensure that all of the tabular values have the
same data format.
0xB215 FM 458 does not respond
Check the communications connection and
configuring.
0xB216 Table is too large
Transfer the table in sub-sets, i.e. either
distribute tabular values over several DBs or
after each partial transfer write new
(additional) tabular values into DB and
transfer.
0xB217 Table is not complete (X / Y values)
Complete the table, there must be a Y value
for each X value.
0xB218 REQTAB is reset during processing Transfer the tabular values again.
0xB219 REQDB reset during processing Transfer the tabular values again.
0xB21A DB number is not valid Specify a valid DB number.
0xB21B
TIMEOUT when receiving the
acknowledge telegram
Check the communications coupling and
configuring. Transfer the tabular values again
0xB21C Invalid processing status Check the configuring of the WR_TAB.
Errors associated with the SFC58 or SFC59 are displayed at the ERROR
output.
3.18.2 Manual mode
3.18.2.1 Application
The "Manual mode" mode represents the simplest way of inserting
tabular values into a configured software package. However, it is
comparatively time consuming as data has to be manually entered or
taught-in from the program.
After the TAB or TAB_D has been correctly configured, the tabular values
can be entered one after another. To start off with, the table size, i.e. the
number of value pairs (=points) should be specified at input NP. If the
table is to be saved in the SAVE area, then input SAV of the must be 1.
Entering tabular
values
