Bit 7, 8 of the header byte Significance
Bit 7, 8= 00 Device-related diagnostics
Bit 7, 8= 01 Identification-related diagnostics
Bit 7, 8= 10 Channel-related diagnostics
Table 3-27 Significance of bit 7 and bit 8 of the header byte
Bits 1 to 6 define the following:
• For device- and identification-related diagnostics the length of the
diagnostic block including the header byte, value range 2...63.
• For channel-related diagnostics, the identification number, value
range 0...63.
Output of additional slave diagnostics data
• Diagnostic bytes 17 to 32 of a slave are output with SEL=1002 to
SEL=1123.
3.5.2 Configuring with COM PROFIBUS
COM PROFIBUS (Windows) should be used when configuring (it is also
possible to use the earlier COM ET200 Version 2.1 for configuring).
Using COM PROFIBUS you can define:
• The number and configuration of the nodes connected to the
PROFIBUS DP bus system
• The baud rate
• Important parameters when using the PROFIBUS DP bus system
SIMADYN D-specific information on COM PROFIBUS:
• Configure the SS52 communications module as SIMADYN D SS52
station type ("SIMADYN" family).
• The input and output addresses should not be specified.
• After completing the configuring, the database is downloaded into
SS52 via the DP bus using the menu command File > Export > DP
master.
• Alternatively, it is also possible to download via RS232. The following
menu command is used to start loading the SS52: File > Export >
SIMADYN Master.
3.5.2.1 Harmonizing with data configured in CFC
The configured software should be harmonized with one another as
follows:
General
Rules
