Siemens D7-SYS User Manual

In just a few steps to the first project
1-10 System- and communication configuring D7-SYS - SIMADYN D
Edition 12.2001
1.5 Testing, compiling and downloading the project
1.5.1 Checking the project consistency and compiling
Step Procedure Result
26
Start the consistency check of your project
with
Chart > Check consistency > Charts as
program, then OK.
Acknowledge the dialog window or evaluate
the error messages via Details.
The result is displayed in the dialog window.
27 Start to compile the project after a successful
consistency check with
Chart > Compile > Charts as program,
then OK.
Acknowledge the dialog window or evaluate
the error messages using Details.
The result is displayed in a dialog window.
You have created your first user project.
1.5.2 Downloading the user project into the SIMADYN D-CPU module
SIMADYN D allows you to
• download online or
• offline.
Maybe you do not have a connection from your PC/PG to the SIMADYN
D station, which is why you can use the possibility of downloading into a
memory module.
Step Procedure Result
28
Select Target system > Download.
You will obtain a dialog window with options.
29 Select "User program" and "Offline"
Insert the memory module into the PCMCIA
slot of the PG/PC.
Start to download with OK.
A progress display shows how the system
and your user program are being
downloaded into the memory module.
30
Insert the memory module into the SIMADYN
D station and re-start it. Your user program is then started.
Introduction
Downloading
offline
