Siemens D7-SYS User Manual

Changeover from STRUC V4.x to D7-SYS
System- and communication configuring D7-SYS - SIMADYN D 4-5
Edition 03.2001
4.1.4 Logic blocks
STRUC
V.4.x
CFC with D7-
SYS
Pre-
assignment
*(‘---‘ = 0)
Comment
Logic blocks
AND12 AND12 --- ---
AND2 - --- Eliminated; replaced by AND
- AND I = 1;
Q = 1;
New; generic at the input
AND22 - --- Eliminated; replaced by AND_W
- AND_W IS = 65535
QS= 65535;
New; generic at the input side
AND4 - --- Eliminated; replaced by AND
AND8 - --- Eliminated; replaced by AND
OR_12 OR_12 --- ---
OR_2 - --- Eliminated; replaced by OR
- OR --- New; generic at the input side
OR_22 - --- Eliminated; replaced by OR_W
- OR_W --- New; generic at the input side
OR_4 - --- Eliminated; replaced by OR
OR_8 - --- Eliminated; replaced by OR
NAN_2 - --- Eliminated; replaced by NAND
- NAND I = 1 New; generic at the input side
NAN4 - --- Eliminated; replaced by NAND
NAN8 - --- Eliminated; replaced by NAND
NOR2 - --- Eliminated; replaced by NOR
- NOR Q = 1 New; generic at the input side
NOR4 - --- Eliminated; replaced by NOR
NOR8 - --- Eliminated; replaced by NOR
XOR2 - --- Eliminated; replaced by XOR
- XOR --- New; generic at the input side
XOR22 - --- Eliminated; replaced by XOR_W
- XOR_W --- New; generic at the input side
NOT NOT Q = 1 ---
NOT02 NOT_W QS = 65535 ---
MFP0F MFP --- ---
PCL0F PCL --- ---
PST0F PST --- ---
PDE0F PDE --- ---
PDF0F PDF --- ---
PIN8 PIN8 --- ---
ETE ETE --- ---
