Changeover from STRUC V4.x to D7-SYS
4-16 System- and communication configuring D7-SYS - SIMADYN D
Edition 03.2001
4.2 Adapting specific connection attributes
The following connection attributes are no longer available in D7-SYS:
• Minimum (MIN),
• Maximum (MAX),
• Format (FORM),
• Signal designator (NAME)
• and LOG texts (LOG0/LOG1)
Specific function blocks of the display utility and the equipment response
utility are involved.
4.2.1 Display utility
For the display utility, the attributes involved, "MIN", "MAX", "FORM", "
'Signal designator' (name) " and "LOG0/1" are configured using new
connections at the blocks involved.
D7-
SYSdesignation
New connections
Process data blocks
DISA_B NAMe
DISA_I NAMe
DISA_W NAMe
DISA_D NAMe
DISA NAMe, FORmat
DISA_T NAMe, FORmat
DISS_B NAMe
DISS_I NAMe, MIN, MAX
DISS_W NAMe
DISS_D NAMe, MIN, MAX
DISS NAMe, MIN, MAX, FORmat
DISS_T NAMe, MIN, MAX, FORmat
Binary value blocks
DISA1B NAMe
LG0 (LOG0-Text)
DISS1B LG1 (LOG1-Text)
Table 4-13 Display utility
