Changeover from STRUC V4.x to D7-SYS
4-14 System- and communication configuring D7-SYS - SIMADYN D
Edition 03.2001
4.1.8 Diagnostic blocks
STRUC
V. 4.x
CFC with D7-
SYS
Pre-
assignment
*(‘---‘ = 0)
Comment
Diagnostic blocks
STG0F STG --- ---
RFG0F RFG --- ---
SQG0F SQG --- ---
SQGBF SQGB --- ---
USF USF --- ---
ASI ASI --- ---
SYF1 SYF1 --- ---
SYF4 SYF4 --- ---
PNO PNO Y = 1 ---
SSD SSD --- ---
PSL PSL --- ---
- DLED LDN = 1 New;
- EPE --- New;
* Corresponds to „0“ as pre-assignment of the various parameters of the
individual function blocks.
Table 4-10 Changes in the diagnostic blocks
4.1.9 SIMOVERT D block
STRUC
V. 4.x
CFC with
D7-SYS
Pre-
assignment *(‘-
--‘ = 0)
Comment
TRV - --- Eliminated; not replaced
* Corresponds to „0“ as pre-assignment of the various parameters of the
individual function blocks.
Table 4-11 Change in the SIMOVERT D block
