3.19.1.3 Status-dependent parameter changes
If selected parameters are only to be changed when the system is in
specific statuses, then you can configure the following functions blocks:
• Function block PSTAT
− to configure a device status
− by entering a password with the authorization level enabled
• Function block PLIM
− defines the statuses and access levels in which a parameter may
be changed
Additional information
on function blocks, refer to the Reference Manual "SIMADYN D Control
system, Function Block Library".
3.19.1.4 Identifying SIMADYN D components
To identify components, “DRIVE Monitor“ evaluates technology
parmeters d998 (1998) and d999 (1999).
d998 Device Special feature
80
SIMADYN D,
general
The parameter range, especially extended for SIMADYN D up to 16 *
2000 parameters, applies.
Parameters are possible in the basic device parameter range (0 ..
999). This means, an identification can result in a random product if a
parameter just by chance coincides with the identification parameter
and value of a drive converter/inverter.
134 T400 /
Parameter range = technology parameters
(1000 .. 1999; 3000 .. 3999)
134
FM 458/
SRT400
Parameter ranges, the function can be set at the central FB
• BASEBOARD: 0 ... 999; 2000 ... 2999
• TECHBOARD: 1000 ... 1999; 3000 ... 3999
Prerequisite: The user selects SIMADYN D or SRT400 and goes online
with the device type.
Dependig on the selected device type, DriveMonitor checks the
identification parameter d998. If the identification was successful, it is not
checked as to whether another device can be recognized.
1. User selects SIMADYN D: If d998 = 80, then the identification routine
is considered to have been successful.
2. User selects SRT400: If d998 = 134, then the identification routine is
considered to have been successful. This means that the user can
only address the technology, also independently of the basic device!
Reserved
parameters
Procedure when
identifying
