3-176 System- and communication configuring D7-SYS - SIMADYN D
Edition 12.2003
Value Diagnostics information
F:
Fault cause
R:
System response
A:
Remedy
22
F: Mode 0: Slave attempts to write into an incorrect address
R: Restricted telegram data transfer functions
A: Select own slave address
23
F: Logical configuring error: Slave-to-slave communications was configured as duplex
operation, however, only one direction is possible for each slave (send or receive)
R: Send and receive the same data
A: Either configure send or receive for slave-to-slave communications
30
F: Physical data transfer faulted on the SIMOLINK ring
R: No telegram data transfer
A: Increase send power (launch power) at one of the subsections, replace medium or
connector
31
F: CRC error (check sum error), data transfer along the ring faulted
R: Telegram failure
A: Increase send power (launch power) at one of the subsections, replace medium or
connector
32
F: Timeout error in the SIMOLINK ring, bus node signals a fault
R: No telegram data transfer
A: FB @SL, evaluates output NDM, beforehand, check node and medium
33
F: Mode 0: Signaled SIMOLINK cycle time (in the special telegram from SL master)
does not correspond to the configured equivalent sampling time
R: Restricted telegram data transfer functions
A: In the HW Config: Adapt the equivalent sampling time of the slave to that of the SL
master
Table 3-67 Error output, SIMOLINK-FBs
3.17.6 Options and accessories
The following are available to configure a SIMOLINK coupling and as
spare part:
Order No. Components
6SE7090-0XX84-0FJ0
SLB module, spare part
(without documentation, without connector)
6SX7010-0FJ00
SLB module, retrofit package
(documentation, 2 fiber-optic cable connectors, 5m
plastic opto-cable, 1 connector for terminal X470)
6SY7000-0AD15
Attachment for SLB
(2 LWL cables, 5m plastic opto-cable)
6SX7010-0FJ50
System package for SLB
(40 fiber-optic cable connectors, 100m plastic opto-
cable, 20 connectors for terminal X470)
Table 3-68 SIMOLINK option modules and accessories
