In just a few steps to the first project
System- and communication configuring D7-SYS - SIMADYN D 1-5
Edition 12.2001
1.2 Creating a new project
Step Procedure Result
1
Double-click on the symbol
.
(if the STEP 7 Assistant starts, cancel this.)
The SIMATIC Manager is opened.
2
Select
File > New.
Enter "My First Project“
into the dialog box, Project.
In the dialog box, select the path
„LW:\Siemens\Step7\S7proj“.
Click on OK.
Your new project is displayed.
3
Select
Insert > Station > SIMADYN D station.
The "SIMADYN D station“ hardware object
is inserted.
1.3 Defining the hardware
The SIMADYN D subrack structure is entered in STEP 7
(HW Config).
Step Procedure Result
4 Select the hardware object
"SIMADYN D station“ and select
Edit > Open object. HW Config is called-up.
5 Open it, if required, the hardware catalog
with View > Catalog.
The hardware catalog with all of the available
family of modules is opened.
6 Select the SR6 from the
SIMADYN D family of modules and Catalog
Subracks and drag it to the (upper) window
The subrack is displayed with six slots.
7 Locate them one after the other
>CPU Modules >PM5 at slot 1
>Expansion Modules >IT41 at slot 2
>Slot covers >SR81 at slots 3 to 6
The subrack is equipped.
8
Open the properties dialog box of the PM5
CPU module with
Edit > Object properties.
The PM5 dialog box with general module
information and the setting registers for
addresses, basic clock cycle, cyclic tasks
and interrupt tasks are displayed.
9
Select the basic sampling time T0 (in this
case: 1 ms) under the basic clock cycle tab.
Click on the cyclic tasks tab and set the
sampling time T1 to 2 ms and T2 to 4 ms.
Click on OK.
The required sampling times are entered.
The properties dialog box is closed.
