Communications configuring
System- and communication configuring D7-SYS - SIMADYN D 3-307
Edition 12.2003
PC configuring station:
SIMATIC NET plug-in cable 727-1 for INDUSTRIAL ETHERNET l
network card SIMATIC NET CP1613
Table 3-103 Hardware prerequisites
NOTE
A CP1613 must be installed in the PC.
System: SIMADYN D
Subrack: SR12.1 12 slots with fan
Slot 1: PM6 CPU (with local service interface)
Slot 1.1: MS51 4 Mbyte Flash memory module
Slot 2: MM11 Communications buffer module
Slot: CSH11 SINEC H1 interface
Table 3-104 Hardware design for the configuring example
3.29.2 Process variables
A SIMADYN D station must be configured and parameterized and a test
chart generated using the CFC configuring tool. The hardware
configuration is described under
Point 26.1 (SIMADYN D hardware
design)
. We will not discuss in detail here how SIMADYN D software is
generated using the CFC. If you require further information refer to the
SIMADYN D Configuring Instructions [4].
3.29.2.1 SIMADYN D software
The CFC chart for the WinCC link does not have to be realized on a
separate chart, but is however recommended as this is more transparent.
The following function blocks are required for the coupling between
SIMADYN D and WinCC for process variables:
• LI - LAN interface block
• VM visualization block
• VI interface block
Hardware
SIMADYN D
hardware
