Communications configuring
3-26 System- and communication configuring D7-SYS - SIMADYN D
Edition 12.2003
Subrack No..1
No. 2
CPU
CS12
CPU
CS22
Fig. 3-11 Point-to-point coupling with CS12
No.. 2
Subrack No.1
No. 3
No. 4 No. 5
8
CPU
CS13
CS22 CPU CPU CPU
CS22 CS22 CS22
CPU
Fig. 3-12 Configuration for four slaves with CS13
