Siemens D7-SYS User Manual

Communications configuring
3-68 System- and communication configuring D7-SYS - SIMADYN D
Edition 12.2003
• A maximum of one transmitter- and/or one receiver block per
communications partner
• Permitted communication utilities:
− process data
− parameter processing of variable-speed drives
• Permitted data transfer mode: Refresh (for receivers, also multiple)
• A maximum of one synchronization function block SYNPRO per SS52
communications module
• A maximum of one diagnostics function block DIAPRO per SS52
communication module
Central block PROFIBUS DP coupling @CSPRO
ECL
ECO
CDM
QTS
-
-
-
-
-
-
-
-
-
GV
I
II
I
BO
BO
CTS
MAA
BDR
CS7 module name.connecto
r
PROFIBUS address
Baud rate
Error class
Error code
Coupling status
Block status
@CSPRO
SLA
LCC
I
I
Only slave functionality
Host CPU monitoring time
Fig. 3-20 Central block, PROFIBUS DP coupling @CSPRO
• Use
This function block initializes and monitors the PROFIBUS DP
coupling (CS7 with SS52). It may only be configured in a sampling
time of 32 ms ≤ TA ≤ 255 ms.
• I/O
ECL, ECO, CDM, QTS and YTS are service- and diagnostics I/O
which are generally used for SIMADYN D start-up (commissioning).
They are not used for configuring.
Further information
on the I/O of the central block PROFIBUS DP coupling @CSPRO,
refer to the User Documentation "SIMADYN D, function block library".
