Communications configuring
System- and communication configuring D7-SYS - SIMADYN D 3-101
Edition 12.2003
SIMADYN D configuring: Address parameters
=>
SINEC L2 FMS: Utility and object
Block
Conne
ction
Channel
name
Address
stage 1
Address
stage 2
FMS utility
Object
location
Object name and
index
CTV AT
Not
relevant
nnmm Any
Client
Write.req
Remote =address stage 2
kkkkkkkk - - Server Local kkkkkkkkbbbbbbpd
MSI nnnn Read.ind nnnn
kkkkkkkk 00mm - Server Local kkkkkkkkbbbbbbpd
nnnn
Information-
Report.req
nnnn
CRV AR
Not
relevant
nnmm Any
Client
Read.req
Remote =address stage 2
kkkkkkkk - - Server Local kkkkkkkkbbbbbbpd
nnnn Write.ind nnnn
Not rele-
vant
00mm -
Client
Information-
Report.ind
Remote Not relevant
Table 3-43 Address parameters
