Communications configuring
System- and communication configuring D7-SYS - SIMADYN D 3-105
Edition 12.2003
SIMADYN D SS5
Edit network parameters - global Source: NETZ1NCM.BPB
Most active L2 station addresses in the network file : 11
Additive topology data :
Number of active remote stations : 10 Highest station address (HSA) : 31
Bus parameter data :
Baud rate : 500000 Baud
Default SAP : 57
Number of telegram retries (max. retry limit) : 1
Medium redundancy : No redundancy
Bus parameter data:
Slot-Time (TSL) : 1000 bit times 2.0000 msec
Setup-Time (TSET) : 80 bit times .16000 msec
Lowest station delay (min TSDR) : 80 bit times .16000 msec
Highest station delay (max TSDR) : 360 bit times .72000 msec
Target-Rotation-Time (TTR) : 60000 bit times 120.0 msec
GAP update factor (G) : 30 bit times
Table 3-46 Mask: "Network parameters - global"
NOTE
The user can edit the highlighted fields.
• The number of masters connected to the bus is specified using
"Number of active remote stations". This information is important to
calculate the "Bus parameter data".
• "Highest station address" is entered corresponding to the number of
stations; stations with higher addresses are not entered in the bus.
• "Baud rate": 500 kbaud is recommended
• "Default SAP", "Max. retry limit" and "Medium redundancy": Use the
default values.
After entering this data and depressing the F1 key, the "Bus parameter
data" are computed. When required, the user can still change them
(generally not necessary).
"Network
parameters -
global" mask
Explanations for
the fields which
can be edited
