Communications configuring
System- and communication configuring D7-SYS - SIMADYN D 3-225
Edition 12.2003
Physical quantity Units Text string to be configured
Torque Newton meter Nm
Kilonewton meter kNm
Meganewton meter MNm
Temperature Kelvin K
Degrees Celsius C
Degrees Fahrenheit F
Enthalpy Joule / Kilogram J/kg
Kilojoule / Kilogram kJ/kg
Megajoule / Kilogram MJ/kg
Voltage Volt V
Kilovolts kV
Millivolts mV
Microvolts uV
Current Ampere A
Milliampere mA
Kiloampere kA
Microampere uA
Resistance (electrical) Ohm Ohm
Milliohm mOhm
Kiloohm kOhm
Megaohm MOhm
Ratio Percentage %
Absolute humidity Gram / Kilogram g/kg
Frequency Hertz Hz
Kilohertz kHz
Megahertz MHz
Gigahertz GHz
Referred torque Newton meter / ampere Nm/A
Acceleration Meter / seconds m/s2
Meter / seconds m/s3
3.19.2 Parameterizing on the Application module FM 458
3.19.2.1 Terminology
• EXM448
EXM 448 communications expansion module of the FM 458
application module
• CBP2
COMBOARD/communications module for PROFIBUS DP
