Changeover from STRUC V4.x to D7-SYS
4-8 System- and communication configuring D7-SYS - SIMADYN D
Edition 03.2001
4.1.5 Input/output blocks
STRUC
V.4.x
CFC with D7-
SYS
Pre-
assignment
*(‘---‘ = 0)
Comment
Input/output blocks
- AENC --- New;
BII8 BII8 --- ---
BIQ8 BIQ8 --- ---
- BIQT --- New;
SBI SBI --- ---
SBQ SBQ --- ---
ADC0F ADC --- ---
AFC0F AFC --- ---
DAC0F DAC --- ---
NAV0F - --- Eliminated; not replaced as only for
EM11
NAV0F2 NAV --- ---
NAV0F4 NAVS --- ---
NAV0F5 - --- Eliminated; not replaced (not
included in the V4 standard library)
NAV0F6 - --- Eliminated; not replaced (not
included in the V4 standard library)
NDB - --- Eliminated; not replaced
* Corresponds to „0“ as pre-assignment of the various parameters of the
individual function blocks.
Table 4-6 Changes in the input/output blocks
The assignment of the input/output blocks to CPU- and peripheral
modules is shown in the following table.
Input/output
block
CPU- and peripheral modules
PM5 PM6 T400 IT41 IT42 EA12 EB11
AENC x x
BII8 xxxxx x
BIQ8 x x x
BIQT x
SBI xxxxx x
SBQ x x x
