Siemens D7-SYS User Manual

Changeover from STRUC V4.x to D7-SYS
4-18 System- and communication configuring D7-SYS - SIMADYN D
Edition 03.2001
4.3 Hardware differences
This Chapter describes the hardware differences between STRUC V.4.x
and D7-SYS
STRUC
V.4.x
CFC with
D7-SYS
Comment
Subracks
SR4 SR12
SR6 SR6
SR12 SR12
SR24 SR24
- SRD Synonym for T400 master drive configuring
- SRT400
CPU modules
-PM5
-PM6
PM16 PM5
PG16 PM5/6 + ITDC
PG26 PM5/6 + ITDC
PS16 PM5/6 + ITDC
PT20
PM5/6 +
T41/42
For further information refer to the SIMADYN D
"Hardware" Manual
PT20G PM5/6 +
IT41/42 +
ITDC
For further information refer to the SIMADYN D
"Hardware" Manual
PT20M
PM5/6 +
IT41/42 +
MM11/4
For further information refer to the SIMADYN D
"Hardware" Manual
PM3 PM5/6
PM4 PM5/6
PT31 PM5/6 + IT41
PT32 PM5/6 + IT41
Expansion modules
IT41 IT41
IT42 IT42
-ITDC
-ITSL
