Changeover from STRUC V4.x to D7-SYS
4-20 System- and communication configuring D7-SYS - SIMADYN D
Edition 03.2001
STRUC
V.4.x
CFC with
D7-SYS
Comment
Program memory modules
MS5 MS5
-MS51
MS55 MS5
MS41 MS5/MS51
MS45 MS5/MS51
MS300 -
Communication modules
SS4 SS4
SS5 SS5
SS51 SS52
SS52 SS52
Interface sub-modules
SS1 SS1
SS2 SS2
SS31 SS31
Table 4-15 Hardware changes due to the changeover to D7-SYS
4.4 Communications
The following communication possibilities are no longer available in
SIMADYN D7-SYS.
STRUC V.4.x designation Comment
DUST4 Replacement: SS52, PROFIBUS DP
Replacement: SS5, SINEC L2 FDL
DUST5 Replacement: SS4, USS with VD1
DUST6 and ET100 Replacement: SS52, PROFIBUS DP and
ET200
Indirect/direct communications Replacement: Process data
Monitor handling Replacement: Service
Equipment response and
equipment response on T300
Replacement: Equipment response on T400
Communications to SIMOVIS Not replaced
Redundant serial coupling Not replaced
Selectable network Not replaced
System trace Not replaced
Table 4-16 Changes in the communication possibilities
