Communications configuring
System- and communication configuring D7-SYS - SIMADYN D 3-7
Edition 12.2003
Used for the
communications
partner
• SIMATIC S5
• Other systems, which are suitable for the
3964R/RK512 protocol (e. g. Allen-Bradley)
Hardware required
• CS7 communications module with SS4
communications module
Communications
utility
• Process data
Central coupling
block
• @CSD03
Features
• Point-to-point connection
• 3964 (R) data transfer protocol with/without RK512
communications protocol
• 2400, 4800, 9600 or 19200 baud
• Either 20mA- or V.24 interface possible
• Maximum net data length, 750 bytes
Table 3-10 DUST3 coupling
DUST3
